| 發動機Engine |
1 |
動力型號 |
170F |
| 2 |
發動機類型Engine type |
4沖程，250傾斜，單缸，強制冷風4-stroke, OHV 250, single cylinder, forced air-cooled |
| 3 |
缸徑×行程Bore×stroke(mm) |
70×54 |
| 4 |
排量Displacement(cm3) |
208 |
| 5 |
最大輸出功率Max. power output(kw/rpm) |
5.0/3600 |
| 6 |
點火反方式Ignition system |
無觸點晶體管點火Non-contact transistor |
| 7 |
啟動方式Start system |
手拉反沖式Recoil start |
| 8 |
油箱容積Fuel tank capacity(L) |
25 |
| 9 |
燃油消耗量Fuel consumption(L/hr) |
1.5 |
| 10 |
持續工作時間Duration of running(h) |
10 |
| 11 |
機油容積Oil capacity(L) |
1.1 |
| 12 |
噪音7米遠Noise(7 meters away) (dB) |
68 |
| 發電機Generator |
13 |
額定頻率Rated frequency(Hz) |
50 |
| 14 |
額定電壓Rated voltage(V) |
230 |
| 15 |
額定功率Rated power(kw) |
2.8 |
| 16 |
最大功率Max. power (kw) |
3 |
| 尺寸Size |
17 |
包裝Dimensions(mm) |
525×395×445=0.1方 |
| 18 |
凈重N.W.(kg) |
45 |
